Bluetooth BT Weighing Scale

Argus has designed & developed Bluetooth BT weighing scales. The Android app and the hardware can be customized to suit the end user requirement.

construction service

Bluetooth BT Weighing Scale Android APP Features


  • User Login & Registration

  • Add IoT Detail

  • Add commodity details



Products Include


  • Weight of Terminal: self-weight lower than 500 g

  • Battery operation: > 3.8v Chargeable Lithium-ion.

  • Display : RGB LCD backlit 6 digits / 2 line display

  • Weighing resolution: 6000 and above (Class III)

  • Capacity & readability to be selectable through password/service mode

  • Tare: 100% of capacity set

  • Overweight cut off: 9e ( 9 times of the readability)

  • Auto Zero : 3 to 5 level setting of Automatic correction of zero shifting

  • Stability Function: Stability symbol is displayed when the weight is stable inside a defined range

  • Display Stabilisation time less than 1 sec

  • Calibration: Digital Input/memory to save calibration data for future recall

  • Statutory requirement: Class III and above, OIML compliances

  • Communication and auto-syncing through Bluetooth

  • Mobile app to automatically recognizes various different weighing point / USERS.

  • Rated Load 0-30 Kg

  • Nominal Output 2.0 � 0.1 mV/V (mili Volt per Volt)

  • Precision C2 / C3 (0.017% & 0.02% FSO comprehensive error)

  • Excitation Voltage 9 VDC - Maximum 12 VDC

  • Platter Size 250mm x 350mm

  • Safe Load 120% of Rated Capacity

  • Ultimate Load 150% of Rated Capacity

  • Non-Linearity <�0.03% of FSO (Full-Scale Output)

  • Creep (30 minutes) <�0.025% of FSO

  • Zero Balance <�1% of FSO

  • Input Resistance 400 � 10 ohms

  • Output Resistance 350 � 5 ohms

  • Insulation resistance Above 5000 Mega ohms.

  • Temp. Compensation -10oC to +40oC

  • Temp. Effect on zero & span < 0.03% FSO/10oC

  • Material Aluminum alloy, Colourless anodized

Bluetooth BT weighing scale India
